下面的maya履帶動畫 api源碼，需要大家自己在vs里編譯。



    //首先是頭文件代碼:

    //頭文件名稱:glideDeformer.h



    #ifndef glideDeformer_h
    #define glideDeformer_h

    #include
    #include
    #include
    #include
    #include
    #include
    #include
    #include
    #include
    #include
    #include
    #include
    #include
    #include
    #include
    #include
    #include
    #include
    #include

    class glideDeformer:public MPxDeformerNode
    {
    public:
        glideDeformer(){};

        virtual
    ~glideDeformer(){};

        static
    void * creator(){return new glideDeformer;};
        static
    MStatus initializeAttr();

        virtual
    MStatus  deform(MDataBlock
    &block, MItGeometry &iter, const MMatrix &mat, unsigned
    int multiIndex);

        bool
    getClosestUVParam(MPoint & point,MFnNurbsSurface &
    surfaceFn,MObject surfaceData,double & paramU,double &
    paramV);
        bool
    getPointFroamSurfacePoint(MPoint & point,MFnNurbsSurface
    & surfaceFn,MObject surfaceData,double & paramU,double
    & paramV,MPoint & outPoint);
        bool
    getPointAfterDeformed(MPoint &
    pointInSurfaceMatrix,MFnNurbsSurface & surfaceFn,MObject
    surfaceData,double & paramU,double & paramV,MPoint &
    pointAffterDeformed);

        static
    MString nodeName;
        static
    MTypeId nodeId;

        static
    MObject glide;
        static
    MObject fixedBase;
        static
    MObject aimDirection;
        static
    MObject drivenSurface;
        static
    MObject baseSurface;
    };
    #endif



    //CPP文件

    #include "glideDeformer.h"

    MString glideDeformer::nodeName=MString("glideDeformer");
    MTypeId glideDeformer::nodeId=MTypeId(0x87031);

    MObject glideDeformer::glide;
    MObject glideDeformer::fixedBase;
    MObject glideDeformer::aimDirection;
    MObject glideDeformer::drivenSurface;
    MObject glideDeformer::baseSurface;

    using std::cout;
    using std::endl;

    MStatus glideDeformer::initializeAttr()
    {
        MFnNumericAttribute
    numattr;
        MFnTypedAttribute
    typedattr;
        MFnEnumAttribute
    enumattr;

        glide=numattr.create("glide","gld",MFnNumericData::kFloat,0.0);

        numattr.setKeyable(true);

        numattr.setStorable(true);

        fixedBase=numattr.create("fixedBase","fxb",MFnNumericData::kBoolean,0);

        numattr.setKeyable(true);

        numattr.setStorable(true);

        aimDirection=enumattr.create("aimDirection","adr",0);

        enumattr.addField("directionU",0);

        enumattr.addField("directionV",1);

        enumattr.setKeyable(true);

        enumattr.setStorable(true);

          drivenSurface=typedattr.create("drivenSurface","dsf",MFnData::kNurbsSurface);

        typedattr.setStorable(false);

          baseSurface=typedattr.create("baseSurface","bsf",MFnData::kNurbsSurface);

        typedattr.setStorable(false);

        //addAttribtue

        addAttribute(glide);

        addAttribute(fixedBase);

        addAttribute(drivenSurface);

        addAttribute(baseSurface);

        addAttribute(aimDirection);

        attributeAffects(glide,outputGeom);

        attributeAffects(fixedBase,outputGeom);

        attributeAffects(aimDirection,outputGeom);

        attributeAffects(drivenSurface,outputGeom);

        attributeAffects(baseSurface,outputGeom);

        return
    MS::kSuccess;
    };


    bool glideDeformer::getClosestUVParam(MPoint &
    point,MFnNurbsSurface & surfaceFn,MObject surfaceData,double
    & paramU,double & paramV)
    {
        surfaceFn.setObject(surfaceData);

        MPoint
    tmpPoint=surfaceFn.closestPoint(point,0,0,false,0.001,MSpace::kWorld);

        MStatus
      stat=surfaceFn.getParamAtPoint(tmpPoint,paramU,paramV,true,MSpace::kWorld,0.001);

        return
    true;
    };


    bool glideDeformer::getPointFroamSurfacePoint(MPoint &
    point,MFnNurbsSurface & surfaceFn,MObject surfaceData,double
    & paramU,double & paramV,MPoint & outPoint)
    {
        surfaceFn.setObject(surfaceData);

        MVector
    tangentU;
        MVector
    tangentV;
        MVector
    normal;
        MPoint
    surfacePoint;
        surfaceFn.getPointAtParam(paramU,paramV,surfacePoint,MSpace::kWorld);

          normal=surfaceFn.normal(paramU,paramV,MSpace::kWorld);

        surfaceFn.getTangents(paramU,paramV,tangentU,tangentV,MSpace::kWorld);

        tangentU.normalize();

        tangentV.normalize();

        normal.normalize();

        double
      matrix[4][4]={{tangentU.x,tangentU.y,tangentU.z,0.0},{normal.x,normal.y,normal.z,0.0},{tangentV.x,tangentV.y,tangentV.z,0.0},{surfacePoint.x,surfacePoint.y,surfacePoint.z,1.0}};

        MMatrix
    surfacePointMatrix=MMatrix(matrix);
          //cout<<"baseSurfacePointMatrix:"<<surfacepointmatrix<<endl;



        outPoint=point*surfacePointMatrix.inverse();

          //cout<<"pointInSurfaceMatrixPosition:"<<outpoint<<endl;

        return
    true;
    };


    bool glideDeformer::getPointAfterDeformed(MPoint &
    pointInSurfaceMatrix,MFnNurbsSurface & surfaceFn,MObject
    surfaceData,double & paramU,double & paramV,MPoint &
    pointAffterDeformed)
    {
        surfaceFn.setObject(surfaceData);

        MVector
    tangentU;
        MVector
    tangentV;
        MVector
    normal;
        MPoint
    surfacePoint;

          surfaceFn.getPointAtParam(paramU,paramV,surfacePoint,MSpace::kWorld);

          normal=surfaceFn.normal(paramU,paramV,MSpace::kWorld);

        surfaceFn.getTangents(paramU,paramV,tangentU,tangentV,MSpace::kWorld);

        tangentU.normalize();

        tangentV.normalize();

        normal.normalize();

        double
      matrix[4][4]={{tangentU.x,tangentU.y,tangentU.z,0.0},{normal.x,normal.y,normal.z,0.0},{tangentV.x,tangentV.y,tangentV.z,0.0},{surfacePoint.x,surfacePoint.y,surfacePoint.z,1.0}};

        MMatrix
    surfacePointMatrix=MMatrix(matrix);
          //cout<<"drivenSurfacePointMatrix:"<<surfacepointmatrix<<endl;

        pointAffterDeformed=pointInSurfaceMatrix*surfacePointMatrix;

          //cout<<"pointAffterDeformedPosition:"<<pointaffterdeformed<<endl;

        return
    true;
    };


    MStatus  glideDeformer::deform(MDataBlock
    &block, MItGeometry & iter, const MMatrix &mat,
    unsigned int multiIndex)
    {
          //cout<<"deform()方法調用..."<<endl;

        MDataHandle
    envelopehandle=block.inputValue(envelope);
        MDataHandle
    glidehandle=block.inputValue(glide);
        MDataHandle
    fixedBasehandle=block.inputValue(fixedBase);
    MDataHandle
    aimDirectionhandle=block.inputValue(aimDirection);


        float
    envelopevalue=envelopehandle.asFloat();
        float
    glidevalue=glidehandle.asFloat();
        short
    aimDirectionvalue=aimDirectionhandle.asShort();
        bool
    fixedBasevalue=fixedBasehandle.asBool();

        if
    (envelopevalue==0.0)
        {

              //cout<<"envelope值為0,跳過deform方法..."<<endl;

            return
    MS::kSuccess;
        };

        MDataHandle
    drivenSurfacehandle=block.inputValue(drivenSurface);
        MDataHandle
    baseSurfacehandle=block.inputValue(baseSurface);


        MFnNurbsSurfaceData
    surfaceDataFn;
        MFnNurbsSurface
    surfaceFn;

        MObject
    drivenSurfaceData=drivenSurfacehandle.asNurbsSurface();
        MObject
    baseSurfaceData=baseSurfacehandle.asNurbsSurface();

        MObject
    drivenSurfaceObj=surfaceDataFn.create();
        MObject
    baseSurfaceObj=surfaceDataFn.create();

        surfaceFn.setObject(drivenSurfaceData);

        surfaceFn.copy(drivenSurfaceObj);

        int
    drivenSurfaceCvU=surfaceFn.numCVsInU();
        int
    drivenSurfaceCvV=surfaceFn.numCVsInV();


        surfaceFn.setObject(baseSurfaceData);

        surfaceFn.copy(baseSurfaceObj);

        int
    baseSurfaceCvU=surfaceFn.numCVsInU();
        int
    baseSurfaceCvV=surfaceFn.numCVsInV();

        cout<<drivensurfacecvu<<"  "<<drivensurfacecvv<<"  "<<basesurfacecvu<<"  "<<basesurfacecvv<<" "<<endl;

        if
    (drivenSurfaceCvU==0||drivenSurfaceCvV==0||drivenSurfaceCvU==0||baseSurfaceCvU==0||baseSurfaceCvV==0)

        {

              //cout<<"drivenSurface或baseSurface不正確，變形不產生..."<<endl;

              MGlobal::displayWarning("drivenSurface或baseSurface不正確，變形不產生...");

            return
    MS::kSuccess;
        };

     if
    (drivenSurfaceCvU!=baseSurfaceCvU||drivenSurfaceCvV!=baseSurfaceCvV)

     {
              //cout<<"drivenSurface與baseSurface不匹配，變形不產生..."<<endl;

            MGlobal::displayWarning("drivenSurface與baseSurface不匹配，變形不產生...");

            return
    MS::kSuccess;
     };


        MPoint
    pt;
        MPoint
    ptAfterDeformed;
        MPoint
    pointInSurfacePointMatrix;
        double
    paramU;
        double
    paramV;
        double
    newParamU;
        double
    newParamV;
        int
    index;
        float
    weight;
        bool
    test;
        if
    (fixedBasevalue==false)
        {

              //cout<<"履帶模式..."<<endl;

              for(iter.reset();!iter.isDone();iter.next())

            {

                  index=iter.index();

                //cout<<"index:"<<index<<endl;

                  weight=weightValue(block,multiIndex,index);

                  //cout<<"weight:"<<weight<<endl;

                if
    (weight==0)
                  {

                      //cout<<"權重為0,此點變形不產生..."<<endl;

                      continue;

                  };

                pt=iter.position(MSpace::kObject);

                  pt=pt*mat;

                //cout<<"position:"<</endl;
